Name: Patient Monitor with Printer - Medical Equipment | MC Kritikos | Cyprus
SKU: 0803834
Price: 1390.00 EUR
Availability: BackOrder

DESCRIPTION

The monitor has abundant functions that can be used for clinical monitoring with adults, pediatrics and neonate. Users may select different parameter configurations according to different requirements. The monitor, power supplied by 100-240V~, 50/60Hz, adopts 12.1” color TFT LCD displaying real-time, date and waveform. It can synchronously display eight-channel waveform and full monitoring parameters equipped with an optional 48mm thermal recorder. The monitor can be connected to the central monitoring system via wire or wireless network to form a network monitoring system. This device can monitor such parameters as ECG, RESP, NIBP/IBP, SpO2, and dual-channel TEMP, etc. It integrates parameter measurement module, display and recorder in one device to form compact and portable equipment. Its replaceable internal battery brings lot of convenient for patient moving.

SPECIFICATIONS

Functions:

12.1” TFT color LCD
Fanless design, quiet, energy-saving and clean, which reducesthe possibility of cross-infection
All-round monitor for adults, pediatric and neonate
With standard interface, oxygen graph, trend graph,big character interface and view bed, convenient to observe
Finish all operations with keys and knobs
Maximum 8-channel waveform synchronous display
Display 7-lead ECG waveform on one screen, cascade ECG wave- form display
Adopt digital SpO2, technology, anti-motion and anti-ambient light Interference, and measurement can be performed under
the circumstance of weak filling

Standard parameters:

ECG, RESP, SpO2, PR, NIBP, dual-channel TEMP

-ECG:

Heart rate (HR)

ECG waveform

Arrhythmia and ST-segment analysis

-RESP:

Respiration rate (RR)

Respiration waveform

-SpO2:

Oxygen saturation (SpO2,)

Plethysmogram (PLETH)

waveform

Pulse rate (PR)

Bar graph

-NIBP:

Systolic pressure (SYS),

Diastolic pressure(DIA)

Mean pressure (MEAN)

-TEMP: T1, T2, TD

-IBP (optional):

CH1: SYS, DIA, MAP

CH2: SYS, DIA, MAP

IBP waveform

-CO2 (optional):

ELCO2, InsCO2 Inspired

Minimum CO2,

AwRR: Air Way Respiration

It has abundant functions, such as audible and visual alarm, trend data storage and output, NIBP measurement, alarm

event marking and drug concentration calculation, etc.

Dimension: 319mm(L) x 167mm(W) x 268mm(H)

Weight: < 3kg (excluding accessories)

Package included

2x Packs 10pcs Pads ECG electrodes
ECG cable
SpO2 Sensor
BP extending tube
Cuff for adults
Temperature sensor
Printer paper 5pcs
Power cable
User manual

See the brochure here

Brand: CONTEC
